  1. It isn’t totally clear. SANS 10400-C (2010), Dimensions gives some guidelines:
    Table 1 ? Room area
    Type of occupancy: All occupancies – Any habitable room other than a kitchen, scullery or laundry – Minimum plan area: 6 m2 with no linear dimension less than 2 m
    Table 2 ? Rooms and their dimensions
    Room or space: Bathroom, shower-room, laundry or room containing a toilet pan – Minimum height: 2,1 m above any area where a person would normally be in a standing position
    The legislation states:
    (1) Any room or space shall have dimensions that will ensure that such room or space is fit for the
    purpose for which it is intended.

  2. It’s not totally clear. SANS 10400-C (2010), Dimensions give some guidelines:
    Table 1 Room area
    All occupancies – Any habitable room other than a kitchen, scullery or laundry – 6 m2 with no linear dimension less than 2 m
    Table 2 Rooms and their dimensions
    Bathroom, shower-room, laundry or room containing a toilet pan – 2,1 m above any area where a person would normally be in a standing position

    The legislation says:

    (1) Any room or space shall have dimensions that will ensure that such room or space is fit for the
    purpose for which it is intended.

  3. What is the minimum width required for a guest toilet?

  4. If pipework needs to be relocated then yes, you will need rider plans.

  5. I am considering moving the existing toilet by 0.5 meters. Do i need to submit a building plan for this?

  6. The only thing is the toilet. Is there one there already? If you are just upgrading an existing one then fine you should not need plans but if it is a new installation and pipework has to be laid to join up with the existing sewage outlet then you will need plans.

  7. Hi Janek. Do you still need plans for a bathroom if there was no structural work? In my case I fitted a shower, toilet and washbasin into an existing room. This was done in 1970s, do I need to get plans for it before I sell my house?

  8. Hi Pieter, yes you will need plans. Any internal or external structural work or any extension of your roof will need approved plans before you do the work. If you do not do plans and you want to sell later and plans are called for they will see that what is there is different to the plans then you could be fined and you will have to do plans as well.

  9. Hi Penny,
    Do need building plans if you want to extend your bathroom with about 1meter and making use of a baywindow?

  10. Thanx Penny

  11. Both lighting and ventilation are covered by Part O of SANS 10400, Lighting and ventilation. If there is sufficient natural ventilation do don’t need a extractor or air vent…

  12. Ordinary ceiling board or tongue-in-groove wood. The ceiling board would need to be skimmed with cretestone or similar. Wood needs to be well sealed. If you use ceiling board it’s preferable in “wet” areas to paint with a good quality paint that is intended to withstand moisture, rather than ordinary chalky (and much cheaper) ceiling paint.

  13. Hi, what type of a ceiling do would you recommend I install in my wet rooms, like shower or bathrooms?

  14. Hi, is it compulsory for the bathroom to have an extracting fan or air vent? what would u suggest I do? thank you in advance
